Features
• Auto-programming speeds installation time
• Supports intelligent addressable devices that includes advanced, next generation CO sensing technology
• Form C contacts for alarm and trouble, Form A for supervisory
• Easy-to-configure rotary addressing
• Optional Ethernet port (SA-ETH) for central station monitoring service, programming, diagnostics and a variety of system reports
• Two programmable switches with LEDs and custom labelling
• Supports horn silence over two wires, and UL 1971-compliant strobe synchronization
• Class B or Class A wiring
• Ground fault detection by module
• Optional multi-protocol Field Server Bridge for interface to 3rd party Building Management Systems
• Supports up to eight serial annunciators, (LCD, LED-only, and graphic interface)
• Can use existing wiring for most retrofit applications
• Upload/download remotely or locally
• Optional USB module for local printing or programming using the configuration utility on a technician’s laptop
• Two-level maintenance alert reporting
• Pre-alarm and alarm verification by point
• Adjustable detector sensitivity
• 4 x 20 character backlit LCD display
• Optional earthquake hardening: seismic Importance Factor 1.5
• Standalone operation
• Transmission test frequency by hour
• Alarm ON command manually activates alarm condition
Specifications
| Brand | Kidde |
